gas, lpg, diesel, heavy oil, dual fuel, biomass, wood, coal, electric
Industrial steam boiler is an important heating equipment for factory production, popular in all the needs of steam or hot water/air/oil. Widely used in food/beverage, paper making, packaged, textile, feed mill, refinery, chemical, building materials, laundry, hotel and other industries.
| Layout: | Horizontal, Vertical, Skid Mounted, Container |
| Capacity: | 0.1 - 50ton, 80 - 28000kw |
| Work Pressure: | 3-38bar, 0.3-3.8Mpa |
| Heat Temperature: | 0-450℃ |
| Applied Industry: | Food, Beverage, Feed, Textile, Paper, Chemical, Package, Refinery, Pharm, Building Material, Hotel... |
Introduction
Yuanda Boiler, China Top 3 Boiler Company/Manufacture Since 1956, Provide Gas, Diesel, Coal, Biomass, Wood, Electric Boiler.
Steam boilers capacity 10bhp to 2500bhp, 0.1ton to 50ton, 100kg to 50,000kg. Hot water boiler capacity 120kW to 14,000kW, 200,000kcal to 1,200,000kcal.
Certified by ASME CE ISO EAC DOSH, reliable service and competitive product.
(1).LHS LSS series vertical gas/oil fired steam boiler(0.1-2 ton) and hot water boiler(120-1400kw);
(2).WNS series gas/oil fired steam boiler(0.5-20 ton) and hot water boiler(350-14000kw);
(3).SZS series gas/oil fired steam boiler(10-60 ton) and hot water boiler(7000-42000kw);
(1).LSS series water tube biomass pellet fired steam boiler(0.12-1 ton);
(2).CWHS series compact biomass pellet fired hot water boiler(40-700kw);
(3).LSG series vertical coal/wood/biomass fired steam boiler(0.5-2ton);
(4).DZH series hand feed coal/wood/biomass fired steam boiler(1-6ton) hot water boiler(700-4200kw);
(5).DZL series coal/wood/biomass fired steam boiler(1-8ton) and hot water boiler(700-5600kw);
(6).SZL series coal/biomass fired steam boiler(2-40ton) and hot water boiler(700-42000kw);
(1).LDR series electric steam boiler(4-500kg) and hot water boiler( 7-350kw);
(2).LDR-SS clean steam generator(4-500kg) and hot water boiler( 7-350kw);
(3).WDR series electric steam boiler (0.5-10 ton) and hot water boiler(350-7000kw);
Pre-sale Service:
1. Design一We help customer to choose the best boiler model according to the different requirements of different industries.
2. Drawing and files一Supply quality certificates, factory-inspect, fuel consumption calculation, cost analysis, foundation drawings, layout drawings, boiler room drawings nased on your needs, etc.
3. Technical Solution一Design completed boiler solution with installation materials for your company.
4. Transportation一We have shipping partners and forwarder for lowest price and safe.
After-sale Service:
1. Provide a full range of boiler and original spare parts.
2. Overseas engineers installation and commissioning service is available.
3. Training in site, to ensure safe operation.
4. 24 hours online, quick respond.
5. Free maintenance and repair for one year and lifetime service.
Quality Assurance
Steel element test→Steel rust cleaning→Welding electrodes drying process→Automatic welding, argon arc welding, expansion welding etc. methods→NDT(Nondestructive Testing) including X-ray Test, Ultrasonic Test, Magnetic particle Test→Hydraulic pressure test.
One-stop Boiler Solution
Please feel free to send all your inquiries or production needs, so we can provide professional boiler solution for you.
Parameter
| Model |
Capacity (Ton/h) |
Horspower (hp) |
Pressure (Mpa) |
steam temperature (℃) |
Feed water temperature (℃) |
Fuel consumption | |
| Light diesel oil(kg/h) | Natural gas(Nm3/h) | ||||||
| WNS 0.5 | 0.5 | 35 | 0.4 to 3.82mpa | 130～450 | 20/105 | 32.5 | 35.7 |
| WNS 1 | 1 | 71 | 0.4 to 3.82mpa | 130～450 | 20/105 | 64.6 | 70.1 |
| WNS1.5 | 1.5 | 120 | 0.4 to 3.82mpa | 130～450 | 20/105 | 96.8 | 105.2 |
| WNS 2 | 2 | 150 | 0.4 to 3.82mpa | 130～450 | 20/105 | 129.3 | 140.3 |
| WNS 3 | 3 | 200 | 0.4 to 3.82mpa | 130～450 | 20/105 | 192.9 | 212.1 |
| WNS 4 | 4 | 300 | 0.4 to 3.82mpa | 130～450 | 20/105 | 258.2 | 283.4 |
| WNS 5 | 5 | 350 | 0.4 to 3.82mpa | 130～450 | 20/105 | 323.5 | 354.7 |
| WNS 6 | 6 | 425 | 0.4 to 3.82mpa | 130～450 | 20/105 | 388.6 | 424.2 |
| WNS 8 | 8 | 550 | 0.4 to 3.82mpa | 130～450 | 20/105 | 514.6 | 566.3 |
| WNS 10 | 10 | 700 | 0.4 to 3.82mpa | 130～450 | 20/105 | 641.7 | 707.8 |
| WNS 12 | 12 | 850 | 0.4 to 3.82mpa | 130～450 | 20/105 | 768.9 | 849.3 |
| WNS 15 | 15 | 1050 | 0.4 to 3.82mpa | 130～450 | 20/105 | 960.1 | 1061.7 |
| WNS 20 | 20 | 1400 | 0.4 to 3.82mpa | 130～450 | 20/105 | 1276.2 | 1415.8 |
| Note: Standard boiler parameter is for your reference, should follow the actual technical data according customer needs & engineer design. | |||||||
